CH-813 0.08-2.5mm SPL- 3 Pole Wire Connector with Spring Lock Lever for 3 Wire line Connection

 This is a CH-813 0.08-2.5mm SPL- 3 Pole Wire Connector with Spring Lock Lever for 3 Wire line Connection. This connector comes with three line connection which can be used for Live, Neutral, and  Earthing wire separately.PCT Spring Lever Connector PCT-212, 213, 215, 215, 218  and CH-812, 813, 2-4, 2-6, etc. comes with compact locking wire connector by a spring lever, which is used for single-strand hardwire with 0.08mm to 2.5mm2 area or soft wire with 0.08mm to 4.0mm2 area (or AWG28 to AWG12). This connector can tolerate the rated voltage up to 400V with an electric current peak of 32A, result in a maximum of 7KW Power.

These connectors are available with different optional models, different sizes, and No. pole on which cables are locked as below Click on it to buy according to your requirement.

The benefit of these connectors over wire Joint:

Features:

1. Compact, Super easy, Reliable, and Reusable.
2. High-grade Insulative Nylon Material
3. Strong Spring Locking Lever
4. Nickel Plated Metal Point Inside
5. Good Temperature Resistance
6. Compact Splicing Connector
7. 4-Conductor Terminal Block
8. With Operating Levers
9. Max. Continuous Service Temperature 85°C

Package Includes:

1 x CH-813 0.08-2.5mm 3 Pole Wire Connector for 3 Wireline Splicing
