DATASHEET
ASAIR Alcohol Sensor Model AGS10ET
Have a Bulk Order?
Click Here Need Support?
Click Here Free Delivery
above ₹499 ×
Get Free Delivery Above Order of ₹499.
3 Months Warranty × Eligible for 3 Months Warranty Cash on Delivery* × Cash on Delivery Option Available.
₨ 250.00
Out of stock
Out of stock
20
People watching this product now!
| Product Type |
Alcohol Sensor |
|---|---|
| Model |
AGS10ET |
| Power supply voltage |
3.0±0.1V DC |
| Minimum supply current |
23mA |
| Typical supply current |
25mA |
| Maximum supply current |
33mA |
| Typical power |
75mW |
| Sampling period |
>=2S/time |
| Warm-up time |
>=120 seconds |
| Working temperature |
0℃～50℃ |
| Working humidity |
0～95%RH |
| Measuring range |
0-99999ug/100ml |
| Typical accuracy |
(25℃ 50%RH) 25% F.S |
| Shipping Weight | 0.001 kg |
| Shipping Dimensions | 7 × 6 × 1 cm |
The AGS10ET sensor is a MEMS ethanol gas sensor with a calibrated digital signal output. It uses dedicated digital module acquisition technology and gas sensing technology to ensure that the product has extremely high reliability and excellent long-term stability.
The alcohol sensor is technically referred to as a MQ3 sensor which detects ethanol in the air. When a drunk person breathes near the alcohol sensor it detects the ethanol in his breathe and provides an output based on alcohol concentration. If there is more alcohol concentration more LED’s would lit
This MEMS gas sensor has the characteristics of low power consumption, high sensitivity, fast response, high reliability and stability, low cost, and a simple driving circuit.
Features:
- High-cost performance
- Good long-term stability
- Excellent quality
- Ultra-fast response
- High sensitivity
- Fast response and recovery time
- Long life
- Digital signal output
- Accurate calibration
Package Includes:
1 x ASAIR Alcohol Sensor Model AGS10ET
