A small rotary encoder is a device used to convert angular position or rotation into digital signals. Here?s an overview of a typical small rotary encoder:

### Key Features:

– **Mechanical Design**: Compact size with a shaft for rotational input.

– **Resolution**: Determines the number of pulses per revolution, influencing accuracy.

– **Output**: Provides digital signals (typically quadrature signals A and B) that indicate direction and step count.

– **Incremental**: Measures relative changes in position, not absolute position.

– **Detents**: Some models have detents or clicks for tactile feedback during rotation.

### Types:

– **Mechanical Rotary Encoder**: Uses mechanical contacts or switches to generate pulses.

– **Optical Rotary Encoder**: Uses optical sensors to detect rotation, offering higher resolution and reliability.

### Applications:

– **User Interface**: Used in control knobs for adjusting settings in consumer electronics.

– **Motion Control**: Provides feedback for positioning in robotics and CNC machines.

– **Measurement**: Converts rotational movement into digital data for precise measurement devices.

– **Industrial Automation**: Integrates into machinery for position sensing and control.

### Example Use:

1. **Mounting**: Secure the encoder shaft to the rotating object or axis.

2. **Connections**: Connect encoder outputs (A, B, and sometimes Z for index pulse) to a microcontroller or encoder interface circuit.

3. **Programming**: Implement software to interpret encoder signals for counting steps or determining direction.

Small rotary encoders are versatile components in electronics and automation, offering precise rotational sensing and control capabilities in a compact form factor suitable for a wide range of applications.
