Linear Actuator 12V (200mm)

### Linear Actuator 12V (200mm) Overview

1. **Type**: Linear Actuator

2. **Specifications**:

– **Voltage**: 12V DC

– **Stroke Length**: 200mm (20cm)

– **Load Capacity**: Varies by model, typically ranges from 20kg to 100kg

– **Speed**: Typically ranges from 5mm/s to 50mm/s, depending on the load and model

3. **Material**:

– **Housing**: Usually made from aluminum or high-strength plastic for durability

– **Internal Components**: Typically steel or other robust metals to handle high loads

4. **Functionality**:

– **Linear Motion**: Converts rotational motion into linear motion to push or pull loads

– **Control**: Controlled by applying a 12V DC power source, often with limit switches to prevent over-travel

5. **Features**:

– **Built-in Limit Switches**: Automatically stop the actuator at the end of its stroke to prevent damage

– **Mounting Holes**: For easy attachment to structures or devices

– **Water-Resistant**: Many models are designed to be water-resistant for use in various environments

### Typical Uses:

– **Home Automation**: Used in adjustable beds, recliners, and automated windows or doors

– **Industrial Automation**: Applies to machinery for precise control of movement and positioning

– **Robotics**: Provides actuation for robotic arms, grippers, and other moving parts

– **Automotive**: Utilized in vehicle systems such as power seats, trunk lifts, and convertible tops

### Key Benefits:

– **Precision Movement**: Provides accurate and repeatable linear motion

– **High Load Capacity**: Capable of handling significant loads, making it suitable for heavy-duty applications

– **Easy Integration**: Can be easily integrated into existing systems with straightforward electrical connections

### How to Use:

1. **Mounting**: Secure the actuator using the provided mounting holes. Ensure it is aligned with the direction of the desired movement.

2. **Electrical Connection**: Connect the actuator to a 12V DC power source. Use a switch or controller to manage the actuator’s movement.

3. **Testing**: Operate the actuator to ensure smooth and precise movement over the full stroke length. Adjust as necessary.

### Example Applications:

– **Adjustable Furniture**: Enables remote or automated adjustment of beds, chairs, and tables.

– **Industrial Equipment**: Used in manufacturing processes for positioning and moving components.

– **Solar Trackers**: Adjusts the angle of solar panels to follow the sun for optimal energy capture.

– **Greenhouses**: Automates ventilation windows and shading systems to maintain ideal growing conditions.

### Installation Tips:

– **Secure Mounting**: Ensure the actuator is securely mounted to prevent movement or misalignment during operation.

– **Proper Wiring**: Follow electrical wiring diagrams and use appropriate connectors to ensure reliable operation.

– **Limit Switch Adjustment**: If the actuator has adjustable limit switches, set them according to your application’s requirements.

### Advantages:

– **Efficiency**: Provides efficient and controlled linear motion with minimal power consumption.

– **Versatility**: Suitable for a wide range of applications in various fields.

– **Reliability**: Designed to operate consistently and withstand harsh conditions.

The Linear Actuator 12V (200mm) is a versatile and powerful component that provides precise and reliable linear motion for various applications. Its robust construction, ease of integration, and high load capacity make it an ideal choice for automation, robotics, and more.
